SMARTER 25Ton Crawler Crane SMQ250A

Brand Name: SMARTER
Model Number: SMQ250A
Dimension: 12955*3000*3000mm
Place of Origin:Jiangsu, China (Mainland)

Product Detail | Technical Information | Packaging

Product Detail

Shanghai Metal Corporation is a professional supplier of SMARTER 25Ton Crawler Crane SMQ250A with high quality and reasonable price.

If you want to know more about Crawler Crane or SMARTER 25Ton Crawler Crane SMQ250A price please feel free to contact us, we will reply you within 24 hours

Technical Information of 25Ton Crawler Crane SMQ250A:

Item			Unit	Amount
Max. lifting capacity			t	25
Boom length			m	10.2-30
Jib length			m	6.5
Max. length of Boom + jib			m	30+6.5
Crane boom angle range			°	-2~80
Working	Steel rope speed	Hoisting	m/min	99
speed	Steel rope speed	Dropping	m/min	99
	Circumgyrate speed		r/min	0~1.8
	Travel speed		Km/h	0~3.9
main hoist multiple			t	4(single rope)
Gradeability			%	40
Engine rating output power/ rotate speed			Kw/rpm	132/2200
Overall weight			t	38
Counterweight			t	10
Overall dimensions			mm	12955X4200X3000
Ground pressure			Kg/cm2	0.7

Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail: 10 days
