SMC Wheel Loader

Product Detail | Technical Information

Product Detail

Shanghai Metal Corporation is a professional supplier of Wheel Loader with high quality and reasonable price.

Low fuel consumption engine that doesn't sacrifice any power. World class and reliable ZF auto transmission with Kick down for energy saving and efficient operation. Powershift for smooth strong gear changes. Torque converter matches engine efficiently. Boom Kick-out & return to carry greatly increases efficiency of repetitive loading tasks.

If you want to know more about Wheel Loader price please feel free to contact us, we will reply you within 24 hours

Technical Information of SMC Wheel Loader:

Engine

Model: YC4A105Z-T20

Type: In Line Direct injection Four-Stroke and Injection Combustion Chamber

Cylinder-Inside: Diameter*Stroke 4-108×132

Rated Power: 75KW

Rated Speed: 2200r/min

Min. Fuel Consumption: ≤230g/km.h

Max.Torque: ≥400N.M

Displacement: 4..837L

Steering System

Model of Steering Device: BZZ5-250

Steering Angle: ±36 o

Min. turning radius: 6581mm

Pressure of the system:12Mpa

Axle

Manufacturer Front: Feicheng Axle Factory

Back: Feicheng Axle Factory

Main Transmission Type: Double Reduction

Final Reducer: Single Stage Final Reducer

Rated Loader of Axle: 8/18.5t

Transmission System：

Type: Single-stage Three Elements

Max. Efficiency: 84.40%

Inlet Pressure: 1.3－1.5Mpa

Outlet Pressure: 0.25－0.3Mpa

Cooling Method: Oil-cooling Pressure Circulation
